Alchip’s Technology and Global Talent Strategy Deliver Record Growth

Alchip Technologies Ltd., a global leader in high-performance computing (HPC) and artificial intelligence (AI) ASIC design and production services, continues its trajectory of rapid growth and technical leadership by pushing the boundaries of advanced-node silicon, expanding its global design capabilities, and building customer-centric solutions that differentiate at the packaging level. In a candid update from CEO Johnny Shen, three pillars emerged as central to Alchip’s strategy: technology leadership, talent deployment, and customer-driven business execution.

TECHNOLOGY: 2nm and 3nm

Alchip is preparing for a significant technology inflection with the introduction of 2nm  design enablement, the first gate-all-around (GAA) transistor node. While 3nm (the final FinFET-based node) will dominate most production designs in 2025, a select few projects are advancing into 2nm, which introduces unique design complexities. These include significantly higher compute power requirements for final sign-off and verification.

During peak 3nm workloads, Alchip leveraged more than 500 servers; for 2nm, even larger compute infrastructures will be required. The company’s 2nm test chip taped out in 2024, with silicon results expected soon. These results will help quantify the PPA (power, performance, area) delta between 3nm and 2nm. While pure 2nm designs might be rare, hybrid approaches—with compute logic in 2nm and analog/mixed-signal components in 3nm chiplets—are becoming common among customers.

Alchip’s early 2nm work is already being validated by one of its more significant customers, who plans to initiate both a test chip and product chip kickoff, within 2025. This underscores Alchip’s credibility as a first-choice ASIC partner for leading-edge silicon.

TEAM: Strategic Global Expansion of Engineering Resources

With 86% of 2024 revenue originating from North America, and with global expansion considerations, Alchip is aggressively shifting its design workforce to Taiwan, Japan, and Southeast Asia. In Vietnam, where the company already employs 30 engineers, headcount is expected to grow to 70–80 by the end of 2025. Similarly, Malaysia’s team is expanding from 20 to approximately 50 engineers. By year-end, over half of Alchip’s engineering workforce will reside outside China.

This distributed R&D model not only ensures IP security and compliance with international regulations but also enables proximity to foundries, customers, and local talent pools. In the United States, Alchip is scaling up its Field Application Engineers (FAEs), Program Managers (PMs), and senior R&D experts to support a customer base that demands nuanced understanding of compute architecture, PPA trade-offs, and roadmap alignment.

For package and assembly support, much of the technical interface remains US-based, with Taiwan-based experts frequently dispatched to co-locate with customers when needed. Testing and product engineering disciplines remain centralized in Taiwan, where Alchip’s reputation as a top-tier semiconductor employer provides a strong pipeline of experienced hires.

BUSINESS: Record-Breaking Growth Driven by Differentiated Solutions

In 2024, Alchip delivered its seventh consecutive year of record financials, with revenue of $1.62 billion and net income of $200.8 million—each marking new highs. These numbers translate into a revenue-per-employee ratio of approximately $2.5 million, placing Alchip among the most productive companies in the semiconductor industry.

Core to this growth is the company’s differentiated package engineering. While customers rarely question Alchip’s ability to deliver on the compute side, most customer inquiries now revolve around packaging strategy. These include determining the optimal HBM stack configuration, interposer design, chiplet integration, thermal modeling, and overall system optimization.

Alchip has completed 18 CoWoS (Chip-on-Wafer-on-Substrate) designs, the most of any ASIC partner, according to TSMC. These designs have varied significantly by customer, each requiring unique interposer geometries, memory bandwidth targets, and form factor considerations. Johnny attributes this capability to Alchip’s focus on emerging, high-tech startups, whose need to innovate quickly forces the company to stay ahead of the technology curve.

This flexibility and deep design experience have made Alchip a go-to partner not only for startups, but also for established tech giants pursuing the next wave of AI and HPC performance.

Outlook: Enabling Tomorrow’s Compute Platforms

With 20–30 tape outs per year, Alchip maintains a rapid feedback loop that continuously hones its methodology, toolchains, and cross-functional workflows. As customers move toward 2nm GAA, 3DIC architectures, and multi-die systems, Alchip is positioning itself as a turnkey provider of silicon, packaging, and system-level integration expertise.

Its tight alignment with TSMC’s roadmap, along with a strategic pivot toward a distributed global engineering footprint, ensures that Alchip will remain a critical player in enabling the future of AI and HPC workloads. The company’s ability to combine advanced silicon design with deep system integration know-how is what makes it not just a service provider—but a true innovation partner.
