                    [post_content] => I attended much of the Jasper users' group a week ago. There were several interesting presentations that I can't just blog about because companies are shy, and some that would only be of interest if you were a user of Jasper's products on a daily basis.

 But for me the most interesting presentations were several on an area that I didn't realize this sort of formal verification was being used for. The big driver is that modern multi-core processors now require much more sophisticated cache control than before. ARM in particular has created some quite sophisticated protocols under the AMBA4 umbrella that they announced at DAC.

In the old days, cache management was largely done in software, invalidating large parts of the cache to ensure no stale data could get accessed, and forcing the cache to gradually be reloaded from main memory. There are several reasons why this is no longer appropriate. Caches have got very large and the penalty for off-chip access back to main memory is enormous. Large amounts of data flowing through a slow interface is bad news.

As a historical note, the first cache memory I came across was on the Cambridge University Titan computer. It had 32 words of memory accessed using the bottom 7 bits as the key and was only used for instructions (not data). This architecture sounds too small to be useful, but in fact it ensures that any loop of less than 32 instructions runs out of the cache and so that trivial amount of additional memory made a huge performance difference.

 Anyway, caches now need to have more intelligence. Instead of invalidating lots of data that might turn out to be stale, the cache controllers need to invalidate on a line-by-line basis in order to ensure that anybody reading an address gets the latest value written. This even needs to be extended to devices that don't even have caches since a DMA device cannot simply go to the main memory due to delayed write-back.

Obviously these protocols are pretty complicated, so how do you verify them? I don't mean how do you verify that a given RTL implementation of the protocol is good, that is the normal verification problem that formal and simulation techniques have been used on for years. I mean how do you verify that the protocol itself is correct. In particular, that the caches are coherent (any reader correctly gets the last write) and deadlock-free (all operations will eventually complete, or a weaker condition, at least one operation can always make progress).

Since this is a Jasper User Group Meeting it wouldn't be wild to guess that you use formal verification techniques. The clever part is that there is a table driven product called Jasper ActiveModel. This creates a circuit that is a surrogate for the protocol. Yes, it has registers and gates but these are not something implementable, they capture the fundamental atomic operations in the protocol. Then, using standard proof techniques, this circuit can be analyzed to make sure it has the good properties that it needed.

 It was a very worthwhile exercise. It turned out that the original spec contain some errors. Of course they were weird corner cases, but that is what formal verification is so good at. Simulation hits the stuff you already thought of. There was one circumstance under which the whole cache infrastructure could deadlock, and another in which it was possible to get access to stale data.

Similar approaches have been taken for verifying communication protocols, which also have similar issues: they might deadlock, the wrong data might get through and so on.





 [post_title] => Formally verifying protocols [post_excerpt] => [post_status] => publish [comment_status] => open [ping_status] => closed [post_password] => [post_name] => formally-verifying-protocols [to_ping] => [pinged] => [post_modified] => 2019-06-14 21:41:15 [post_modified_gmt] => 2019-06-15 02:41:15 [post_content_filtered] => [post_parent] => 0 [guid] => https://www.semiwiki.com/word5/uncategorized/formally-verifying-protocols.html/ [menu_order] => 0 [post_type] => post [post_mime_type] => [comment_count] => 0 [filter] => raw ) [1] => WP_Post Object ( [ID] => 866 [post_author] => 4 [post_date] => 2011-11-15 10:59:00 [post_date_gmt] => 2011-11-15 10:59:00 [post_content] => With worldwide annual media tablet shipments forecast changing –growing- almost every quarter, the latest from ABI research calling for shipment to approach 100 million units in 2012 and passing 150 million in 2014, with the same kind of forecast for smartphone passing 400 million units this year (438 million) and approaching the billion units shipment for 2016, no doubt that these two applications are the key drivers for the semiconductor market for the next five years.




But the good question is which type of semiconductor? Let’s have a look at the compared bill of material (BOM) for Media Tablet and Smartphone:



From the first column (smartphone) we extract a total value of about $200 and $300 for the column associated with media tablet. Clearly, a significant value is coming from display, touch screen and mechanical, especially when looking at media tablet. Because this site is semiwiki (and not displaywiki or mechawiki... even if it would be interesting) we will concentrate on the SC content only. We have built the following table, restricted to SC, where we can see that the BOM ratio is no more 2 to 3, but rather 8 to 9. The SC content for both is very similar: Nand Flash, DRAM and Application processor can be seen as identical (which is no more true if you compare a Media Tablet enabled with 32GB Nand Flash with a Smartphone with 16 GB Nand Flash, so this is a “theoretical” case). The Nand Flash and DRAM suppliers are well known (Samsung, Elpida, SanDisk…), and it would be highly doubtful that a fabless new comer emerges in these two segments. That why we have decided to “zoom” to the semiconductor content excluding the memories. Then the BOM goes down to $42 for the smartphone and $50 for the media tablet.




We have addressed in a previous postthe Application Processor segment, pretty crowded, as we count seven big players (Broadcom, Freescale, Intel, Marvell, Nvidia, Qualcomm, Renesas, ST-Ericsson and TI) and a bunch of new comers, some of these starting to be well established now (Mtekvision or Spreadtrum):

  • Anyka Technologies Corporation
  • Beijing Ingenic Semiconductor Co., Ltd.
  • Chongqing Chongyou Information Technologies Company
  • Fuzhou Rockchip Electronics Co., Ltd
  • Hisilicon Technologies
  • Leadcore Technology
  • MagicEyes Digital, Inc
  • MStar Semiconductor
  • Mtekvision
  • Novatek Microelectronics
  • Spreadtrum
  • Shanghai Jade Technologies Co., Ltd.

Because this segment is so crowded, why not looking elsewhere? It could be connectivity (WiFi, WLAN or Blutooth) or sensors (gyroscope or accelerometer) chips… but we have selected the Power Management (PM) IC: the PM emiconductor content reach 40% of the SC BOM for media tablets and 20% for smartphone.

Let’s try to make a quick assessment of the PM IC Total Addressable Market (TAM). IPnest has already built a smartphone shipment forecast for 2010-2016 (see blogin Semiwiki), and we have forecast information available for media tablet from ABI research. To derive the PM IC TAM forecast for 2011-2016, we have to:

  • consolidate these two forecasts (media tablet and smartphone shipment)
  • Assess the price erosion, or ASP evolution, for PM IC

First, the combined forecast by unit shipments, for 2010-2016:





Then, we can calculate the Total Available Market for the Power Management IC, in both Smartphone and Media Tablet Application, associating the PM IC respective ASP in each of these application. We have neglected the potential decline in PM IC usage in media tablet or smartphone, as it is unlikely to happen: to provide satisfaction to the end user by increasing the time between charging, the trend is to provide systems with better power management capabilities. As well, we have neglected the potential growth pervasion for power management devices. We think such a growth would lead to higher TAM, and higher TAM would increase the number of competitors, leading to more drastic price erosion. But we have assumed the same price erosion rate than for the application processors, or 33% over a five years period of time. With these assumptions, the power management IC market segment is expected to reach $6 Billion by next year, and up to $8 Billion by 2016.



Power management market segment has been relatively neglected by analyst or bloggers so far, at least when compared with the application processor segment, where you can find multiple articles. Looking at this IC segment market weight allow to better understand the long term strategy of companies like Texas Instrument, trying to consolidate position on the PM segment (which, by the way, is NOT part of the Wireless Business Unit) by running high price acquisitions, when one can feel that they defocus from the wireless market – which is completely wrong! They are just focusing more on the power management segment... the application becoming a kind of enabler for the PM IC!

Eric Esteve from IPnest [post_title] => Media Tablet & Smartphones to generate $6 Billion market in… power management IC segment by 2012, says IPnest [post_excerpt] => [post_status] => publish [comment_status] => open [ping_status] => closed [post_password] => [post_name] => media-tablet-smartphones-to-generate-6-billion-market-in-power-management-ic-segment-by-2012-says-ipnest [to_ping] => [pinged] => [post_modified] => 2019-06-14 21:41:13 [post_modified_gmt] => 2019-06-15 02:41:13 [post_content_filtered] => [post_parent] => 0 [guid] => https://www.semiwiki.com/word5/uncategorized/media-tablet-smartphones-to-generate-6-billion-market-in-power-management-ic-segment-by-2012-says-ipnest.html/ [menu_order] => 0 [post_type] => post [post_mime_type] => [comment_count] => 0 [filter] => raw ) [2] => WP_Post Object ( [ID] => 862 [post_author] => 20367 [post_date] => 2011-11-15 06:00:00 [post_date_gmt] => 2011-11-15 06:00:00 [post_content] =>  It is always a treat to listen to the nVidia earnings conference call as Jen Hsun Huang offers his take on the industry as well as a peek at his company’s future plans. Invariably a Wall St. analyst will ask about Windows 8 and Project Denver – the code name for the ARM based processor designed to run Windows 8 with great graphics performance and in categories that Jen Hsun describes in meticulous detail as Tablets and Clamshells. In last week’s call, Jen Hsun went out a little further on the ski tips as he claimed that he is going to take ARMs architecture into market segments it hasn’t gone before through “extensions.” Let me cut to the chase, he is going to build a CPU with x86 instruction translation with the help of the cadre of engineers imported from Transmeta.

Before I go any further, let me back up for those of us who didn’t get the Microsoft update. Up until a Microsoft Analyst meeting in September, the standard line from the Redmond folks was that everything that ran on Windows 7 would run on Windows 8, regardless of the processor (x86 or ARM). Renee James of Intel mentioned at a Spring Intel conference that x86 apps would not run on ARM based Windows 8 machines. Microsoft had a cow and let the world know that Ms. James wasincorrect. Turns out she was correct and she should know since she heads up the Software Group at Intel that makes sure that Windows 8 and applications will run on Intel’s newest processors. Uh Oh, the Emperor Just Lost His Clothes!

Just to set some leveling here… Intel and Microsoft are going through a long divorce. It will be messy and stretch out for years, maybe even decades. Renee James’ comments are the type that are strategic and the wording is reviewed in great detail by multiple people, including CEO Paul Otellini. So Paul is saying to Steve Ballmer, "Time to come clean buddy." And to ARM, Otellini is saying, "x86 isn’t dead in PCs by a long shot." Or maybe nVidia has a different answer.

That brings us up to Microsoft’s September statement from Steven Sinofsky on what Windows 8 can run:

STEVEN SINOFSKY: Sure. I don't think I said quite that. I think I said that if it runs on a Windows 7 PC, it'll run on Windows 8. So, all the Windows 7 PCs are X86 or 64-bit.

We've been very clear since the very first CES demos and forward that the ARM product won't run any X86 applications. We've done a bunch of work to enable that -- enable a great experience there, particularly around devices and device drivers. We built a great deal of what we call class drivers, with the ability to run all sorts of printers and peripherals out of the box with the ARM version.

Oh what would we do without analysts to tell us the future?

Back in the days when Transmeta was still around, it shopped itself to the usual suspects. Jen Hsun passed on a direct buyout and instead hired some of the best engineers. Rumors flew around about nVidia building a direct x86 competitor to Intel, however the true value of Transmeta engineering was in the x86 compatible software translator that sat on top of a VLIW core with some hardware hooks for performance. The significance of Transmeta was both the translator and the discovery that the world was about to ditch MHz and go for mobile wireless devices with extra long battery life that emphasized the visual experience over some PC Mag benchmark. All the benchmarks in the day however centered around jumping in and out of Office Applications making tweaks here and there demonstrating why 1GHz Pentiums were much more valuable than 933MHz ones.

Bear in mind that Jen Hsun Huang expects the Project Denver question at every quarterly earnings call, so here in his own words:

“Project Denver, our focus there is to supplement, add to ARM’s capabilities by extending the ARM’s architecture to segments in a marketplace that they're not, themselves, focused on. And there are some segments in the marketplace where single-threaded performance is still very important and 64 bit is vital. And so we dedicated ourselves to create a new architecture that extends the ARM instruction set, which is inherently very energy-efficient already, and extend it to high-performance segments that we need for our company to grow our market. And we're busily working on Denver. It is on track. And our expectation is that we'll talk about it more, hopefully, towards the end of next year. And until then, until then I'm excited, as you are.”

Essentially, nVidia’s model is that for most of the PC market what matters is compatibility and graphics performance. In the nVidia model the x86 CPU is a sidecar. In the future you will pay more for a better graphics experience than CPU performance. If the performance of Jen Hsun's multicore ARM is way beyond what a typical Microsoft Office User expects. An x86 software translator on top of the ARM cores at 20% performance of native should be just fine. I picked 20% - maybe it’s 25% or 30% but you get the idea. To be unique and to get away from the pack (TI and Qualcomm), nVidia will implement some instruction extensions to enable the translator. Since nVidia already has the gaming community on its side writing games that directly go to the graphics GPU, Jen Hsun can envision a scenario where it is Game Over!




 [post_title] => Jen Hsun Huang’s Game Over Strategy for Windows 8! [post_excerpt] => [post_status] => publish [comment_status] => open [ping_status] => closed [post_password] => [post_name] => jen-hsun-huangs-game-over-strategy-for-windows-8 [to_ping] => [pinged] => [post_modified] => 2019-06-14 21:41:12 [post_modified_gmt] => 2019-06-15 02:41:12 [post_content_filtered] => [post_parent] => 0 [guid] => https://www.semiwiki.com/word5/uncategorized/jen-hsun-huangs-game-over-strategy-for-windows-8.html/ [menu_order] => 0 [post_type] => post [post_mime_type] => [comment_count] => 0 [filter] => raw ) [3] => WP_Post Object ( [ID] => 863 [post_author] => 9491 [post_date] => 2011-11-14 17:27:00 [post_date_gmt] => 2011-11-14 17:27:00 [post_content] =>  Tensilica has been around for quite a long time. Their key technology is a system for generating a custom processor, the idea being to better match the requirement of the processor for performance, power and area as compared with a fully-general purpose control processor (such as one of the ARM processors). Of course generating a processor on its own isn't much use: how would you program it? So the system also generates custom compilers, virtual platform models and so on. Everything that you need to be able to use the processor.

I've said before in the context of ARM that what is most valuable is not the microprocessor design itself, it is the ecosystem that surrounds it. That is the barrier to entry, not the fact that ARM does a reasonable job of implementing processors.

In the early days of Tensilica, this technology was what they sold. Early adopters who needed a custom processor could buy the system, design their processor, put it on an SoC, program it using the compiler and model. ARC (now part of Synopsys via Virage) was the other reasonably well-known competition. I remember talking to them once and they admitted that lots of people really wanted a fixed processor because they wanted to know the performance in advance, for example.

Tensilica found the same thing. There isn't a huge market of people wanting to design their own processor. But there is a huge market of people who want a programmable block that has certain characteristics, and a market for people who want a given function implemented without having to write a whole load of Verilog to create a fully-customized solution.

So Tensilica have been taking their own technology and using it to create blocks that are easier to use. Effectively they are the custom processor design experts so that their customer don't have to be. The first application that got a lot of traction was 24-bit audio.

More recently, there is the ongoing transition to LTE (which stands for Long Term Evolution, talk about an uninformative and generic name) for 4G wireless. This is very complicated, and will be high-volume (on the handset side anyway, base-station not so much).

Difficult to use but flexible technologies often end up finding a business like this. The real experts are in the company and it is easier for them to "eat their own dogfood" then it is to teach other people to become black-belt users.




 [post_title] => Not your father's Tensilica [post_excerpt] => [post_status] => publish [comment_status] => open [ping_status] => closed [post_password] => [post_name] => not-your-fathers-tensilica [to_ping] => [pinged] => [post_modified] => 2019-06-14 21:41:10 [post_modified_gmt] => 2019-06-15 02:41:10 [post_content_filtered] => [post_parent] => 0 [guid] => https://35.226.139.164/uncategorized/863-not-your-fathers-tensilica/ [menu_order] => 0 [post_type] => post [post_mime_type] => [comment_count] => 4 [filter] => raw ) [4] => WP_Post Object ( [ID] => 861 [post_author] => 28 [post_date] => 2011-11-13 16:38:00 [post_date_gmt] => 2011-11-13 16:38:00 [post_content] => Can semiconductor devices change the temperature of the earth? The heat from my Dell XPS changes the temperature of my lap! A 63” flat screen TV changes the temperature of my living room. I just purchased six of the latest iPhones for my family (under duress) and signed up for another two years with Verizon, so our carbon footprint changes once again.

As computing goes from the desktop to the laptop to the fingertop with a total available market (TAM) of 7B+ people, power has become a critical mess. A recent Time Magazine article, 2045: The Year Man Becomes Immortal suggests that we will successfully reverse-engineer the human brain by the mid-2020s. Replicating the computing power of the human brain is one thing, unfortunately, replicating its power efficiency is quite another!

Power efficiency in the semiconductor design and manufacturing ecosystem is overwhelming design reviews: cost and power, performance and power, temperature and power, etc.... Who knows this better than Chris Malachowsky, co-founder and CTO of NVIDIA? Chris and the IEEE Council on EDA bought me lunch at ICCAD last week. Chris talked about everything from superphones to supercomputers and the semiconductor power challenges ahead.

Chris was quick to point out that NVIDIA is a processor company not a graphics (GPU) company, with $3.5B in revenue, 6,900 employees, and 2,000+ patents. Chris currently runs a 50+ PhD research group inside NVIDIA. One of the projects his group is working on is a supercomputer capable of a MILLION TRILLION calculations per second for the Department of Energy ExascaleProgram, all in the name of science. The hitch is that it can only consume 20MWs!

NVIDIA has 3 very synergistic market segments for their technology:

[LIST=1]
  • Mobile (Tegra)
  • Gaming/Visual Computing (GForce/Quadro)
  • Supercomputing (Tesla)

    The largest market today is computer gaming at $35B+ but fingertop computing (mobile) is where the hyper growth is as it intersects all three markets. We now live in a pixel based world and whoever controls those pixels wins!

    One of the worst kept secrets is NVIDIA’s new Tegra 3 architecture, which is an example of what Chris Malachowsky called a mutli-disciplinary approach to semiconductor power management. The best write-up is Anandtech’s NVIDIA's Tegra 3 Launched: Architecture Revealed.

    The Tegra 3 is a quad core SoC with almost twice the die size of its predecessor, from 49mm^2 to around 80mm^2, built on the TSMC 40nm LPG process. The performance/throughput of Tegra 3 is about five times better than last year’s Tegra 2 with 60%+ less power consumption. The Tegra 4 (code name Wayne) has already been taped out on TSMC 28nm and will appear in 2012. We will never see a better process shrink than 40nm to 28nm in regards to performance and power so expect the Tegra 4 to be extra cool and fast!

    The key to the Tegra 3’s low power consumption is the fifth ARM Cortex 9 “companion” core, running at 500MHZ. You can run one to four cores at 1.3GHZ or just the companion core for background tasks, thus the power savings, and thus the mutli-disciplinary approach to low power SoC realization. You will see a flood of Tegra 3 based devices at CES in January so expect NVIDIA to have a Very Happy New Year!

    The fingertop computing technology appetite is insatiable, and with a TAM of 7B+ units you can expect many more multi-disciplinary approaches to low power semiconductor design and manufacturing, believe it!




     [post_title] => Semiconductor Power Consumption and Fingertop Computing! [post_excerpt] => [post_status] => publish [comment_status] => open [ping_status] => closed [post_password] => [post_name] => semiconductor-power-consumption-and-fingertop-computing [to_ping] => [pinged] => [post_modified] => 2019-06-14 21:41:10 [post_modified_gmt] => 2019-06-15 02:41:10 [post_content_filtered] => [post_parent] => 0 [guid] => https://35.226.139.164/uncategorized/861-semiconductor-power-consumption-and-fingertop-computing/ [menu_order] => 0 [post_type] => post [post_mime_type] => [comment_count] => 3 [filter] => raw ) [5] => WP_Post Object ( [ID] => 860 [post_author] => 3 [post_date] => 2011-11-12 10:36:00 [post_date_gmt] => 2011-11-12 10:36:00 [post_content] => 3D-IC design has become a popular discussion topic in the past few years because of the integration benefits and potential cost savings, so I wanted to learn more about how the DRC and LVS flows were being adapted. My first stop was the Global Semiconductor Alliance web site where I found a presentation about how DRC and LVS flows were extended by Mentor Graphics for the Calibre tool to handle TSV (Thru Silicon Via) technology. This extension is called Calibre 3DSTACK.



    With TSV each die now becomes double-sided in terms of metal interconnect. DRC and LVS have to now verify the TSV, plus front and back metal layers.



    The new 3DSTACK configuration file controls DRC and LVS across the stacked die:



    A second source that I read was at SOC IP where there were more details provided about the configuration file.

    This rule file for the 3D stack has a list of dies with their order number, postion of each die, rotation, orientation, location of the GDS layout files and associated rule files and directories.

    To do the parasitic extraction requires new information about the size and electrical properties of the microbumps, copper pillars and bonding materials.

    One methodology is to first run DRC, LVS and extraction on each die separately, then add the interfaces. The interface between the stacked dies uses a separate GDS, and LVS/DRC checks are run against this GDS.

    For connectivity checking between dies text labels are inserted at the interface microbump locations.

    With these new 3D extensions then Calibre can run DRC, LVS and extraction on the entire 3D stack.
    A GUI helps you to visual the 3D rules and results from DRC, LVS and extraction:


    TSMC Partner of the Year Award
    Based on this extension of Calibre into the 3D realm, TSMC has just announced that Mentor was chosen as the TSMC Partner of the Year. IC designers continue to use the familiar Calibre rule decks with the added 3DSTACK technology.


    Summary
    Yes, 3D-IC design is a reality today where foundries and EDA companies are working together to provide tools and technology to extend 2D and 2.5D flows for DRC, LVS and extraction.

    Further Info
