Samtec Puts AI’s Interconnect Bottleneck on Display at ECOC and AI Infra Summit

Samtec is using two major 2026 industry events to make a clear engineering argument: faster accelerators alone will not determine the performance of next-generation artificial-intelligence infrastructure. The copper and optical links connecting chips, packages, boards, racks and data centers must scale in bandwidth, density and energy efficiency at the same pace. Its appearances at the AI Infra Summit in California and ECOC in Spain put that interconnect challenge—and Samtec’s proposed solutions—directly in front of system architects.

At the AI Infra Summit, scheduled for September 15–17 at the Santa Clara Convention Center, Samtec will demonstrate high-speed copper and optical technologies in booth 304. The announced exhibits include PCI Express 5.0 running over FireFly optical cable assemblies, Si-Fly HD 224-Gbps PAM4 co-packaged and near-chip systems, and early Si-Fly HD technology targeting 448-Gbps PAM4 and PAM6 signaling. These are not simply connector demonstrations; they address how systems move enormous volumes of data among GPUs, accelerators, memory pools, switches and storage.

The centerpiece is the Si-Fly HD CPX architecture. Samtec describes it as an electrically pluggable platform for co-packaged copper and optics that can fit on a 95-by-95-millimeter or smaller substrate. Its SFCM connector mounts directly to the package substrate and mates with Samtec’s SFCC cable assembly or compatible optical assemblies. Moving the interconnect onto the package avoids the insertion loss associated with ball-grid-array breakouts and long printed-circuit-board traces, making a complete passive direct-attach-copper channel at 224 Gbps practical.

That architecture matters because signal integrity becomes unforgiving as lane rates rise. At 224 Gbps, attenuation, crosstalk, reflections and jitter consume the channel budget quickly. Designers can compensate with retimers and equalization, but every active component adds power, heat, latency, cost and potential failure points. Shortening the electrical path and placing conversion closer to the silicon preserves signal quality while giving architects the flexibility to use copper for short reaches and optics where distance or density makes electrical transmission inefficient.

Samtec will reinforce that message through two technical presentations. Matt Burns, its global director of technical marketing and a good friend to SemiWiki, is scheduled to discuss whether 224/448-Gbps systems can combine copper and optics, followed by a session outlining a practical route to 400G AI scale-up and scale-out implementations. The distinction is critical: scale-up links join accelerators into a tightly coupled compute domain, while scale-out networks connect larger numbers of nodes. Both require high throughput, but their reach, latency, topology and power constraints differ.

Days later, Samtec will take the same silicon-to-system strategy to ECOC 2026, running September 21–23 in Málaga. Its participation in the Optical Internetworking Forum’s live interoperability demonstration is especially significant. OIF says the showcase will involve 39 member companies, allowing components from different suppliers to operate together in realistic link configurations. Such demonstrations turn standards and implementation agreements into measurable evidence that equipment can be mixed without proprietary lock-in.

Interoperability is essential for AI infrastructure because no single vendor supplies the entire data path. Accelerators, switch silicon, connectors, cables, optical engines, transceivers and test equipment must meet common electrical, optical and management expectations. OIF’s work on 224G and 448G Common Electrical I/O, coherent optics, co-packaging, management interfaces and energy-efficient links helps reduce uncertainty for hyperscalers and equipment makers planning multigeneration platforms.

Together, the two events show Samtec positioning itself beyond the traditional connector category. Its value proposition spans the distance from the package edge to external optical links, supported by signal-integrity expertise and pluggable architectures. The broader message is that AI’s next performance gains depend on moving data efficiently, not merely calculating faster. By demonstrating dense copper and optical systems—and proving them alongside other vendors—Samtec is addressing the bandwidth, thermal and deployment risks that increasingly define scalable AI infrastructure. For customers, that can mean shorter design cycles, clearer upgrade paths and better utilization of costly compute silicon. For the industry, it helps convert ambitious 224G and 448G roadmaps into deployable, multivendor systems worldwide.
