A webinar presented Last week introduced two free aids to evaluating synchronizer Mean Time Between Failures (MTBF). The first, MetaACE LTD, is used to characterize the intrinsic parameters needed to calculate MTBF (tau and Tw). This limited version of MetaACE supports up to 250 circuit nodes, which is enough for a typical C-only-extracted synchronizer netlist. You will need the transistor model supplied by your foundry, in addition, but that is all that is required to get an approximate value for the MTBF at any process corner, value of supply voltage or junction temperature.

To calculate the MTBF of a synchronizer based on a fully extracted netlist will require the professional version ofMetaACE. This tool is typically used before tapeout, but the limited version is useful at an earlier point in the design cycle to compare different synchronizer designs. It can also be used to optimize a design for synchronizer service where clock-to-Q can be allowed to increase in order to minimize metastability resolving-time.

Another aid introduced during the webinar was A Public Synchronizer design that can serve as a benchmark to compare with a standard-cell flip-flop you may be planning to use. This Public Synchronizer is a straightforward master-slave circuit that includes a scan circuit for good testability. However, the layout of its regenerating transistors has been optimized for synchronizer service.

If you are contemplating solving a clock-domain-crossing issue with a synchronizer, it might be a good idea to take a look at the Blendics webinar to see if these free aids to design might be useful to you.
