2.5 nm Transistor, Thermal Electronic Layer Etching/ALE

Arthur Hanson

Active member
This looks like one more method of advancing Moore's law while increasing performance. Not only that, the team that developed them found they perform 60% better than FinFETS. Any thoughts or comments on this process would be appreciated, such as potential time to market and the viability in manufacturing processes for mass production.
